CMOS 600TVL Super Mini Wired Camera Cute Ultra Mini Camera CCTV Camera with 6pcs LEDs Night Vision for 1.2G /2.4G wireless
(edit with the Customer Reassurance module)
(edit with the Customer Reassurance module)
(edit with the Customer Reassurance module)
Features:
1.HD 600 TV line
2.Super mini size , easy to hide in any object
3.Can be for 1.2G or 2.4G wireless
Parameters:
PICK UP ELEMENT | Single chip 1/3 CMOS | |
SYSTEM | NTSC | PAL |
NUMBER OF PIXEL | NTSC: 656(H) x 492 (V) | PAL: 786(H) x 576 (V) |
SENSOR DIMENSION | 4.75mm(H) x 3.55mm(V) | |
HORIZONTAL RESOLUTION | Approximately 480TV Lines | |
SENSITIVITY | 0.008Lux/F1.2 | |
LENS & VIEW ANGLE | 0.5mm F1.2 / 90° | |
S/N RATIO | 48dB | |
AUTO GAIN CONTROL | OUT | |
WHITE BALANCE CONTROL | OUT | |
BACK LIGHT COMPENSATION | OUT | |
VIDEO OUT | 1.0V p-p/75ohm | |
WEIGHT&DIMENSIONS | MC900-V9: 2g; 10.5*10.5*19mm | |
WORK CURRENT | 71-17mA | |
POWER REQUIREMENT | 4.2-24V | |
OPERATING TEMPERATURE | - 10° C ~ +50°C less than 90% RH | |
Connection | Red DC5V /12V ,Black GND , Yellow VIDEO OUT |
Package:
1 x Mini camera
